| 产品特性：电磁阀 | 品牌：DELTAPOWER | 型号：DE-S2I-00 |
| 加工定制：是 | 产品别名：电磁阀阀芯 | 适用范围：油压 |
| 标准：美标 | 类型：直通式 | 压力范围：3000psi |
| 连接形式：外螺纹 | 材质：不锈钢 |
DE-S2I-00 DELTA POWER, HYDRAULIC VALVE, CARTRIDGE DIRECTION CONTROL TWO WAY, 7/8"-14 UNF THREAD, DELTA SERIES, 2 WAY NORMALLY CLOSED BI-DIRECTIONAL POPPET VALVE, UP TO 4.0 GPM, 3000 PSI, BUNA STANDARD DE-S2I-00
DELTAPOWER DE-S2I-00电磁阀阀芯
DE-S2I DIRECT ACTING POPPET, 2 WAY, NORMALLY CLOSED, BIDIRECTIONAL
DESCRIPTION:10 size, 7/8-14 thread, “Delta” series, solenoid operated, 2 way normally closed, bidirectional poppet valve.（描述：10通径，7/8-14螺纹，“Delta”系列，电磁阀操作，2路常闭，双向锥阀。）
OPERATION：When de-energized the DE-S2I blocks flow from (1) to (2) and (2) to (1). When energized the valve allows flow from (1) to (2) and (2) to (1)（操作：当断电时，DE-S2I阻断从(1)到(2)和(2)到(1)的流量。当通电时，阀门允许从(1)到(2)和(2)到(1)的流量。）
OPERATION OF MANUAL OVERRIDE OPTION: to override, turn the manual override screw clockwise. To release turn the manual override screw counter-clockwise.（手动超越选项操作：要超越，顺时针旋转手动超越螺钉。要松开，逆时针旋转手动控制螺钉。）
FEATURES：特征：
? Hardened parts for long life.（? 硬化部件，使用寿命长。）
? Efficient wet-armature construction.（?高效湿式电枢结构。 ）
? Cartridges are voltage interchangeable.（?墨盒电压可互换。）
? Manual override option.（?手动覆盖选项。）
? Industry common cavity.?手动覆盖选项。
? Unitized, molded coil design.（?统一的模压线圈设计。）
? Continuous duty rated solenoid.（?连续额定工作电磁阀。）
? Optional coil voltages and terminations.（?可选的线圈电压和终端。）
? Optional “I” Coil: Weatherproof, Thermal Shock, Immersion Safe（?可选“I”线圈:防风雨，热冲击，浸没安全）
